# A Newly developed analysis model predicts the anisotropic mechanical behavior of sheet metals within seconds using only microstructural information … published in a top 1.4% JCR-ranked journal
# Rapid analysis of metal forming behavior without repeated material testing expected to improve process design efficiency for automotive and battery applications
CHANGWON, South Korea — Korea Institute of Materials Science (KIMS) , led by President Chul-jin Choi, announced that a research team led by Kyung Mun Min and Seonghwan Choi of the Materials Processing Research Division has developed a new analysis model capable of predicting the anisotropic mechanical behavior of sheet metals within seconds using only microstructural information of metallic materials. The technology is expected to dramatically reduce the time and cost required for designing forming processes for metallic materials used in automobiles and batteries, as it enables fast and accurate prediction of how sheet metals stretch and deform without complex repetitive experiments.
Sheet metals are widely used in automobile body panels, battery cases, and electronic components. During forming processes, however, undesirable deformation modes such as tearing, wrinkling, and localized thinning can occur. To prevent such problems, it is essential to predict how materials deform depending on direction. Conventional approaches required repetitive mechanical testing in multiple directions or highly precise computational models involving extensive calculation time and cost.
The KIMS research team focused on crystallographic orientations, which describes the alignment of grains—the microscopic crystalline units that make up metallic materials. Sheet metals consist of numerous grains, and manufacturing processes often create preferred orientations within the microstructure. As a result, even the same metal can exhibit different deformation behavior depending on the direction of applied force. Existing analysis models generally assumed either that all grains deform equally or that all grains experience identical stress conditions. In reality, however, metallic materials exhibit intermediate deformation characteristics that cannot be fully explained by either assumption alone. To address this limitation, the research team proposed a new analytical approach that quantitatively represents these intermediate deformation characteristics through a single intermediate variable. Based on crystallographic orientations for individual grains, the model comprehensively calculates microscopic deformation behavior and predicts how the entire sheet metal deforms depending on direction with significantly improved speed and accuracy.
The developed model was successfully applied to various metallic materials, including two representative commercial stainless steels, industrial aluminum alloys, and oxygen-free high-conductivity (OFHC) copper. The model accurately predicted directional deformation behavior while dramatically reducing calculation time from several hours to only a few seconds compared with conventional high-precision analysis methods. The researchers demonstrated that deformation behavior of sheet metals can be rapidly predicted using only crystallographic orientation data without repetitive directional mechanical testing, significantly improving the efficiency of formability evaluation for metallic materials.
The technology is expected to be applicable to various sheet metal forming processes involving automotive steel sheets, aluminum sheets, and copper foils. In particular, it is anticipated to be highly useful for evaluating formability during the early stages of new material development as well as for die design and process optimization in actual manufacturing environments. The model is also expected to help reduce trial and error by predicting forming issues such as tearing and wrinkling in advance, thereby improving process design efficiency and reducing manufacturing costs.
“This study is meaningful in that it presents an efficient analytical approach capable of rapidly predicting forming behavior using only microstructural characteristics of metallic materials,” said Kyung-mun Min, senior researcher at Korea Institute of Materials Science. “We expect this technology to contribute to reducing the time and cost required for process design of metallic sheet materials used in automobiles, batteries, and electronic components.”
The research was supported by the Convergence Research Group Project of the National Research Council of Science and Technology (NST). The results were published online on April 1, 2026, in the International Journal of Plasticity, one of the world’s leading journals in mechanics and mechanical engineering ranked in the top 1.4% of the JCR category.
The research team plans to expand the model’s applicability to a broader range of metal forming analyses and further develop it into a finite element analysis model capable of predicting property changes during deformation for industrial applications.
-----------------------------------------------------------------------
###
About Korea Institute of Materials Science(KIMS)
KIMS is a non-profit government-funded research institute under the Ministry of Science and ICT of the Republic of Korea. As the only institute specializing in comprehensive materials technologies in Korea, KIMS has contributed to Korean industry by carrying out a wide range of activities related to materials science including R&D, inspection, testing&evaluation, and technology support.
International Journal of Plasticity
From Taylor to Sachs: An intermediate constraint based on a single microstructural parameter
1-Apr-2026
