observed the process using electrons, and at other times using photons in the X-ray energy range – and although in both cases we were observing the same substances reacting with one another, we saw something different,” explains Prof. Magdalena Parlinska from the Institute of Nuclear Physics, Polish Academy of Sciences (IFJ PAN) in Cracow, one of the lead authors of an article published in the prestigious scientific journal Nano Micro Small.
In transmission electron microscopy (TEM), an electron beam in vacuum passes through a sample which is no more than a few dozen nanometers thick. Unfortunately, the vacuum inside the microscope prevents the examination of samples containing water or suspended in liquid. This problem is solved by holders featuring a liquid cell (LC) comprising two chips with windows fitted with two thin silicon nitride membranes, through which the imaging electron beam passes. In the experiment carried out by physicists in Cracow, the nanocubes were placed on a membrane, and a solution of chloroauric acid was delivered to the liquid cell via capillaries designed to supply fluids to the cell.
Scanning transmission X-ray microscopy (STXM) operates on a similar principle to TEM, but instead of electrons, it uses a focused beam of soft X-rays, i.e. photons. Given that the energies of the photons are significantly higher here than in the optical range, STXM also allows for high image magnification, albeit slightly lower than that achieved with electron microscopy. The technique does, however, have a major advantage: by scanning the sample with photon beams of appropriately selected energies, it is possible to obtain information about the material’s chemical composition and even its degree of oxidation at a specific point in the image. The source of X-ray radiation for STXM microscopy in the presented studies was the SOLARIS synchrotron, the main facility of the National Centre for Synchrotron Radiation at the Jagiellonian University in Cracow.
“In the reaction of copper oxide nanocubes with a solution of chloroauric acid that we are investigating, the cubes themselves act as templates for the gold structures that are to be formed,” explains Dr. Joanna Depciuch-Czarny (IFJ PAN), co-author of the discovery in question. “When we observed the reaction using a photon beam, we ultimately saw a material composed of gold-rich, hollow nanoboxes. But when we looked at the samples using an electron beam, the gold was simply deposited on the walls of the copper nanocubes, and the cubes showed no sign of disappearing.”
Why did a reaction that appeared to be exactly the same result in the formation of hollow gold nanoboxes (a material with a large surface area, potentially ideal for use as a catalyst, for example) in one case, whilst in the other the gold merely coated the copper nanocubes with a thin layer? The culprit turned out to be the manner, in which the researchers observed the reacting cubes.
Both the electron beam and the photon beam react with water. The reactive chemical species formed as a result of irradiation alter the local environment, favoring either the acceptance of electrons (reduction) or their release (oxidation); they also affect the activity of hydrogen ions – and thus the acidity or alkalinity of the solution, as measured by the widely used pH scale. It is known from literature on the subject that an electron beam creates a locally more acidic environment, which inhibits the oxidation and etching of copper oxide, whilst simultaneously promoting the reduction of gold ions and their deposition. In contrast, a photon beam does not cause such a drop in the solution’s pH as in the case of electrons, which aids both the deposition of gold and the oxidation/dissolution of copper oxide, ultimately leading to the formation of hollow gold nanoboxes.
The experimental results were confirmed using numerical models describing ion transport, surface reactions and the radiolysis of water, carried out using the computing power of the Cyfronet AGH Academic Computing Centre.
“This article addresses fundamental issues: we have demonstrated that the beam used for microscopic imaging of successive stages of chemical reactions need not be a passive observer. On the contrary, it can become one of the actors on the chemical stage, capable of actively influencing the course of events. We are already working on further publications, using materials containing other elements and presenting the issue from a more applied perspective,” concludes Prof. Parlinska.
The research presented here was funded by the Polish National Science Centre.
The Henryk Niewodniczański Institute of Nuclear Physics (IFJ PAN) is currently one of the largest research institutes of the Polish Academy of Sciences. A wide range of research carried out at IFJ PAN covers basic and applied studies, from particle physics and astrophysics, through hadron physics, high-, medium-, and low-energy nuclear physics, condensed matter physics (including materials engineering), to various applications of nuclear physics in interdisciplinary research, covering medical physics, dosimetry, radiation and environmental biology, environmental protection, and other related disciplines. The average yearly publication output of IFJ PAN includes over 600 scientific papers in high-impact international journals. Each year the Institute hosts about 20 international and national scientific conferences. One of the most important establishments of the Institute is the Bronowice Cyclotron Centre (CCB), which is an infrastructure unique in Central Europe, serving as a clinical and research centre in the field of medical and nuclear physics. In addition, IFJ PAN runs four accredited research and measurement laboratories. IFJ PAN is a member of the Marian Smoluchowski Kraków Research Consortium: “Matter-Energy-Future”, which in 2012-2017 enjoyed the status of the Leading National Research Centre (KNOW) in physics. In 2017, the European Commission granted the Institute the HR Excellence in Research award. As a result of the categorization of the Ministry of Education and Science, the Institute has been classified into the A+ category (the highest scientific category in Poland) in the field of physical sciences.
CONTACTS:
Prof. Magdalena Parlińska
Institute of Nuclear Physics, Polish Academy of Science
tel.: +48 12 6628160
email: magdalena.parlinska@ifj.edu.pl
SCIENTIFIC PUBLICATIONS:
“Electrons Make Shells, Photons Make Boxes: Unmasking Radiation Chemistry in Liquid-Phase Imaging”
B. Alavi, J. Depciuch, M. S. Shakeri, K. Sobczak, K. Matlak, M. Parlińska
Nano Micro Small 2026, e75209
DOI: 10.1002/smll.75209
LINKS:
The website of the Institute of Nuclear Physics, Polish Academy of Sciences.
Press releases of the Institute of Nuclear Physics, Polish Academy of Sciences.
IMAGES:
HR: http://press.ifj.edu.pl/news/2026/09/16/IFJ260916b_fot01.jpg
Copper cube decorated by gold nanoclusters, synthesized under the electron beam in basic environment. The image was acquired using energy dispersive X-ray spectroscopy mapping. False colors indicate the distributing of gold (yellow) and copper (red) in the investigated structure. (Source: IFJ PAN)
HR: http://press.ifj.edu.pl/news/2026/09/16/IFJ260916b_fot02.jpg
Gold nanoparticle-coated copper cubes. Artificially colored scanning electron microscope (SEM) image. (Source: IFJ PAN)
