Diffractive deep neural networks (D 2 NNs) are optical systems composed of successive transmissive layers optimized through deep learning to perform computational tasks in an all-optical manner. The UCLA research team, led by Professor Aydogan Ozcan, has developed a pyramid-structured diffractive optical network, which scales its layers pyramidally to align with the direction of image magnification or demagnification. This design ensures high-fidelity image formation in one direction while inhibiting it in the opposite direction, achieving unidirectional imaging with fewer diffractive degrees of freedom. The researchers also demonstrated that by cascading multiple P-D 2 NN modules, higher magnification factors can be achieved, showcasing the system's modularity and scalability.
The P-D 2 NN architecture was experimentally validated using terahertz (THz) illumination. The diffractive layers, fabricated through 3D printing, were tested under continuous-wave THz illumination. The experimental results, involving different designs for magnification and demagnification, closely matched the numerical simulations. The outputs in the forward direction accurately reflected the magnified or demagnified input images, while the outputs in the backward direction produced low-intensity, non-informative results, as desired for unidirectional imaging.
Applications and Future Prospects :
The P-D 2 NN framework's ability to suppress backward energy transmission while dispersing the original signal into unperceivable noise at the output makes it a promising tool for various applications. These include optical isolation for photonic devices, decoupling of transmitters and receivers in telecommunications, privacy-protected optical communications, and surveillance.
Moreover, the system's polarization-insensitive operation and ability to deliver high-power structured beams onto target objects while protecting the source from counterattacks highlight its potential in various defense-related applications.
Authors of this article include Bijie Bai, Xilin Yang, Tianyi Gan, Jingxi Li, Deniz Mengu, Mona Jarrahi, and Aydogan Ozcan, who are affiliated with UCLA Electrical and Computer Engineering Department. Professor Ozcan also serves as an associate director of the California NanoSystems Institute (CNSI).
This research was supported by the US Office of Naval Research (ONR).
Light Science & Applications
Pyramid diffractive optical networks for unidirectional image magnification and demagnification
